| Technical Parameters |
| Features | (Video + picture + WeChat promotion), intelligent interconnection (micro / WiFi / 3G / RS232 / Bluetooth / digital / wireless / high speed), weight, body weight (BMI), blood pressure, heart rate, fat, intelligent sound; Application / cloud interface) |
| Measuring range | |
|
height：60cm-210cm
body weight：5- 500kg
blood pressure：0--299mmHg
Pulse: 40 hops / min - 180 hits / min
Fat rate：5.0- 50%
Basal metabolism：385kcal- 5000kcal
|
| measurement accuracy | |
|
height：（±0.5cm )
body weight：（±0.1kg )
Blood pressure: ± 4mmHg, less than 5% of the reading
|
| LCD screen | Full view LCD HD 10.1-inch display system, intelligent guided voice / animation tips, multimedia player |
| smart system | The latest intelligent control system, automatic intelligent self-test system |
| Shape design | Ergonomic design, metal rugged chassis |
| Height measurement | Imported ultrasonic probe, automatic ultrasonic technology to measure height (no touch), accurate algorithm |
| Weight measurement | Precision sensor, accurate measurement |
| Health analysis | support |
| Diet recommendations | support |
| Send the phone | support |
| company name | Can be configured (can be screen operation) |
| Voice broadcast | Selection and self-configuration (screen operation) |
| Print configuration | Choose whether to print, free to configure the print bar start / end ad text (screen operation) |
| Support Units | CM(厘米)、M(米)、KG(公斤)、LB(英磅)、PUL(英尺英寸)（Can be screen operation） |
| Support video | 3GP、MP4、RMVB、RM、FLV、MP4、AVI and other common formats |
| Support picture | PNG、JPG/JPEG and other common formats |
| Support communication | WiFi、bluetooth, serial port、3G/4G、cloud interface, etc. (some optional) |
| multi-lingual | support |
| Health system | Compatible with electronic medical records (EMR) system |
| Recommended Use | Hospitals, pharmacies, clinics, schools, shopping malls / supermarkets, public security systems, gymnasiums, medical centers and bath centers and other departments and units |
| Optional (body temperature, Oximetry, blood glucose meter, etc.), can be customized (Identification: ID / IC card / ID / social security card / bracelet, etc.)
support chain, health machine Supporting program.
|
| voltage | AC160V-250V,50HZ |
| Power consumption | ≤15W (About 60 hours of continuous work) |
| Machine height | 2350mm |
| Machine weight | 41.5kg |
| Package Size | 1790*385*220mm, 695*410*475mm (L*W*H) |
| Manufacturer | Zhengzhou Shanghe Electronic Technology Co., Ltd |
| Manufacturers Hotline | (+86)15638813509 |
